Lindy 50m CAT5/6 USB 2.0 Extender

SKU: LIN42693

$128.98

RRP $169.00 SAVE $40.02
Share:

or 4 payments of $32.24 with Info



Product Details

  • Extends a single USB port up to 50m using low cost Cat.5e/6 network cable (not included)
  • Plug & Play installation, OS independent
  • Perfect for use with USB 2.0 devices such as storage devices, printers, scanners, mice and keyboards
  • Supports USB 2.0 High Speed and USB 1.1 Full Speed / Low Speed
  • 2 year warranty

The Lindy 50m USB 2.0 CAT5 Extender can be used to extend the distance between a USB peripheral device and host computer by up to 50m.

It consists of a local unit which connects to the computer and a remote unit that connects to the device.

A standard, low cost CAT5e/6 network cable (not included) is then used to bridge the connection between the two units.

Connecting a USB hub to the receiver also gives additional access to a larger number of USB devices.

For added convenience this USB 2.0 Extender is supplied with a power supply, which can be connected should additional power be required.

Package Contents

  • Transmitter unit
  • Receiver unit
  • Multi-Country Power Supply (EU, UK, US & AUS)
  • Lindy Manual



Technical Information

Specifications
  • USB Standard: USB 2.0
  • Supported Bandwidth: 480Mbps
  • Maximum Distance: 50m (164.04ft)
  • Transmission Medium: Cat.5/5e/6 or higher network cable
  • Chipset: LG-8311



 Connectors
  • Transmitter Input: USB Type A (Male)
  • Transmitter Output: RJ45 (Female)
  • Receiver Input: RJ45 (Female)
  • Receiver Output: USB Type A (Female)
  • Power: 3.5/1.35mm DC socket



 Physical Properties
  • Dimensions WxDxH: 30x60x15mm (1.18x2.36x0.59in)
  • Housing Material: Plastic
  • Net Weight: 0.064kg (0.14lb)
  • Operating Temperature: -0° - 70°C (32°F - 158°F)
  • Storage Temperature: -20°C - 80°C (-4°F - 176°F)
  • Humidity: 0 - 90% RH (non-condensing)
  • Power Requirements: 5VDC 2.1A
  • Colour: Black



Miscellaneous
  • Packaging Type: Carton Box
  • Packaging Dimensions: 140x130x85mm (5.51x5.12x3.35in)
  • Gross Weight: 0.235kg (0.52lb)
  • Warranty (Years): 2
  • Certificated: CE, FCC, RoHS & REACH



(LIN42693)

SKU LIN42693
Model # 42693
Barcode # 4002888426930
Brand Lindy
Shipping Weight 0.3920kg
Shipping Width 0.070m
Shipping Height 0.200m
Shipping Length 0.220m
Shipping Cubic 0.003080000m3
