Others YHDAA YHD-5700DB 2D Wireless Bluetooth Barcode / QR Code Scanner

HID/SPP Mode and can switch.

Supports Bluetooth/2.4G/Wired Mode, 3modes for option.

Supports Handheld/Continuous/Auto-Induction, 3modes for option.

Support over sixteen different countries' keyboard layout.

Excellent decoding ability, high speed and low error rate.

Built-in 2600mAh battery, super-long standby time.

Support for smart phones/tablets/computers; compatible for Windows /Android /IOS.

It can read not only all kinds of 1D barcodes on paper but also barcodes on the mobile.

phone and computer screen, and it also can read 2D barcodes.

Can be customized according to customer demand.

Technical parameters

ProductSpecification: YHD-5700DB 2D Wireless Bluetooth Barcode Scanner
Scanner parameters:
Transmission mode: Bluetooth/2.4G/Wired	Storage: 100,000 barcodes
Distance: 50m/100m/1.5m	Sensor: 640 480 CMOS
CPU: ARM 32-bit Cortex	Battery: 3.7V-2600mAh
Indication: Buzzer LED	Light aimer:617nm LED
Resolution: 4mil	Anti-inference: 0-100000Lux Max
Decoding speed: 500scans/sec	Illumination:6500K LEDs
Printing Contract: ≥25%	Interface: USB, USB-COM
Button life: 8000,000 times	Material: ABS+PC
Trigger Mode: Handheld,Continuous,Auto-Induction
Depth Of Field	13mil-EAN13	50-250mm
4mil-code39	60-100mm
20mil-QR	40-300mm
10mil-PDF417	40-280mm
Decode Capability: 1D: UPC-A, UPC-E, EAN-8, EAN-13, Code 128, Code 39, Code 93, Code 11, Interleaved 2 of 5, Matrix 2 of 5, Standard 2 of 5, Coda bar, MSI Plessey, RSS, etc. 2D: QR Code, Data Matrix, PDF417, Aztec code, Maxicode, etc.
Scanning angle: Angle of rotation360, inclination± 65, declination ± 60
Working current: 3.3Vx200mA	Standby current: 18uA-5mA
Workingtime: 7to 10days	Charging power: 5V-400mA
Certificate: CE, FCC, RoHS, IP54	Drop test: 2m

12-month Australian Consumer Law Guarantee
