FEATURE SUMMARY

  • 80 PLUS Platinum certified
  • Compact SFX Size - 125 (L) x 100 (W) x 63.5 (H) mm
  • Tight Voltage Regulation
  • Cable-free Connection Design
  • S3FC - Fanless until 30 % load
  • SFX to ATX Expandability
  • Gold plated connectors



    •
Technical Specifications
80PLUS Platinum
Cybenetics Efficiency Level TBA
Cybenetics Noise Level TBA
Form Factor Intel SFX 12 V / ATX 12 V
Dimensions 100 mm (L) x 125 mm (W) x 63.5 mm (H)
Fan Information Fan Size 92 mm
Fan Control Premium Hybrid Fan Control
Fan Bearing Fluid Dynamic Bearing
Life Expectancy 50,000 hours at 40 C, 15 % - 65 % RH
Cable Information Modularity Fully Modular
Cable type Flat black cables
Electrical Features Operating Temperature 0 - 50 C (derating from 100 % to 80 % from 40 C to 50 C)
MTBF @ 25 C, excl. fan 100,000 hours
AC Input Full Range
Protection OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental Safety and EMC cTUVus, TUV, CB, CCC, BSMI, EAC, CE
Environmental Compliance Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty 10 Years



Power Output
AC Input Voltage: 100 V - 240 V
Current: 10 - 5 A
Frequency: 50 Hz - 60 Hz
DC Output Rail +3.3 V +5 V +12 V -12 V +5 VSB
Maximum Power 20 A 20 A 62 A 0.3 A 3 A
100 W 744 W 3.6 W 15 W
Total Continuous Power 750 W



12-month Australian Consumer Law Guarantee

SKU V28-PSUSEAFOCUS750SPX
Barcode # 882016002014
Brand Seasonic
Shipping Weight 5.0000kg
Shipping Width 0.170m
Shipping Height 0.100m
Shipping Length 0.240m
Shipping Cubic 0.004000000m3
