Seasonic SS-460H1U H1U 1U POWER SUPPLY
Seasonic Fountain & Ponds Accessories
This Seasonic industrial power supply is 80 PLUS efficiency rated and it features a high reliability ball bearing fan. Fully modular cables and easy-swap connectors add a new dimension to its versatility, while the Seasonic Smart and Silent Fan Control (S2FC) system make it a silent performer. These units comply with the latest PFC harmonics (IEC1000-3-2 and EN61000-3-2 standards) and are protected against short circuit, over voltage and over power. On the 3.3 V rail there is no minimum load requirement for this unit to work properly.
DC Outputs | ||||||
+3.3 V | +5 V | +12 Combined | -12 V | +5 Vsb | Total continuous power | Input Type |
20 A | 21 A | 34 A | 0.8 A | 3 A | 460 W | 100240 VAC |
130 W (max.) | 408 W | 9.6 W | 15 W |
12-month Australian Consumer Law Guarantee
Input frequency 50 / 60 Hz Efficiency (220 V AC - 240 V AC, full load) 83 % (typical) Efficiency(100 V AC - 120 V AC, full load) 80 % (typical) Dielectric withstand, input to frame/ground 1800 VAC, 1 sec Dielectric withstand, input to output 1800 VAC, 1 sec Line regulation ± 1 % (typical) Load regulation ± 5 % (typical) Cross regulation ± 5 % (typical) MTBF, full load @ 25 C ambient (excl. DC fan) > 100,000 hours Active Power Factor Correction 99 % (typical)
SKU | V28-PSUSEA460H1U80P |
Barcode # | N/A |
Brand | Seasonic |
Shipping Weight | 3.0000kg |
Shipping Width | 0.300m |
Shipping Height | 0.100m |
Shipping Length | 0.400m |
Shipping Cubic | 0.012000000m3 |
