FEATURES

• Super-High Efficiency, 80 PLUS Platinum Certified
• Fully Modular
• ATX 3.0 and 16-Pin PCIe Gen 5 Cable (12VHPWR)
• Top-Quality 135 mm Fluid Dynamic Bearing Fan
• Premium Hybrid Fan Control
• Tight Voltage Regulation (12 V, 5 V and 3.3 V) [± 3 %]
• Gold Plated High Current Terminal (MB, CPU and PCIe)


• SPECIFICATIONS

  Technical Specifications
  80PLUS	Gold
  Cybenetics Efficiency Level	TBA
  Cybenetics Noise Level	TBA
  Form Factor	Intel ATX 12 V
  Dimensions	160 mm (L) x150 mm (W) x 86 mm (H)
  Fan Information	Fan Size	135 mm
  Fan Control	Premium Hybrid Fan Control
  Fan Bearing	Fluid Dynamic Bearing
  Life Expectancy	50,000 hours at 40 C, 15 % - 65 % RH
  Cable Information	Modularity	Fully Modular
  Cable type	Flat black cables
  Electrical Features	Operating Temperature	0 - 50 C (derating from 100 % to 80 % from 40 C to 50 C)
  MTBF @ 25 C, excl. fan	150,000 hours
  AC Input	Full Range
  Protection	OPP, OVP, UVP, OCP, OTP, SCP
  Safety and Environmental	Safety and EMC	cTUVus, TUV, CB, CCC, BSMI, EAC, CE
  Environmental Compliance	Energy Star, RoHS, WEEE, ErP Lot 6, REACH
  Warranty	10 Years



  Power Output
  AC Input	Voltage: 100 V - 240 V
  Current: 13 - 6.5 A
  Frequency: 50 Hz - 60 Hz
  DC Output	Rail	+3.3 V	+5 V	+12 V	-12 V	+5 VSB
  Maximum Power	25 A	25 A	83 A	0.3 A	3 A
  125 W	996 W	3.6 W	15 W
  Total continuous power	1000 W
