FEATURE SUMMARY

  • Super-High Efficiency, 80 PLUS Platinum Certified
  • Fully Modular
  • ATX 3.0 and 16-Pin PCIe Gen 5 Cable (12VHPWR)
  • Top-Quality 135 mm Fluid Dynamic Bearing Fan
  • Premium Hybrid Fan Control
  • Tight Voltage Regulation (12V, 5V and 3.3V) [± 3%]
  • Gold Plated High Current Terminal (MB, CPU and PCIe)




    •
  •
Technical Specifications
80PLUS Platinum
Cybenetics Efficiency Level TBA
Cybenetics Noise Level TBA
Form Factor Intel ATX 12V
Dimensions 160 mm (L) x 150 mm (W) x 86 mm (H)
Fan Information Fan Size 135 mm
Fan Control Premium Hybrid Fan Control
Fan Bearing Fluid Dynamic Bearing
Life Expectancy 50,000 hours at 40 C, 15 % - 65 % RH
Cable Information Modularity Fully Modular
Cable type Flat black cables
Electrical Features Operating Temperature 0 - 50 C (derating from 100 % to 80 % from 40 C to 50 C)
MTBF @ 25 C, excl. fan 150,000 hours
AC Input Full Range
Protection OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental Safety and EMC cTUVus, TUV, CB, CCC, BSMI, EAC, CE
Environmental Compliance Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty 10 Years



Power Output
AC Input Voltage: 100 V - 240 V
Current: 15 - 7.5 A
Frequency: 50 Hz - 60 Hz
DC Output Rail +3.3 V +5 V +12 V -12 V +5 VSB
Maximum Power 25 A 25 A 100 A 0.3 A 3 A
125 W 1200 W 3.6 W 15 W
Total Continuous Power 1200 W



12-month Australian Consumer Law Guarantee

SKU V28-PSUSEAVERPX1200
Barcode # 882016002427
Brand Seasonic
Shipping Weight 5.0000kg
Shipping Width 0.190m
Shipping Height 0.120m
Shipping Length 0.350m
Shipping Cubic 0.008000000m3
